Core:

ExpeditionSiteHoleCoreGearTypeTop Depth (m)Drilled LengthBottom DepthMCD OffsetRecoveryRecovery(%)OrientedSectionsCore CatcherCuratorIGSNComments
ELGYGY 1 C 168 RIG Q 485,3 2,85 488,15 0 2,8 98,2456140350877 no 3 yes NN BGRB5011RCP4001 Reamed 2.85 m, recovery 2.73 m +7 cm CC, greenish-gray volcanites, sec 1, box 30 sec 2+ CC: box 31

Sections:

SectionSection LengthCurated LengthTop Depth (m)Bottom Depth (m)CuratorCCMCD TopBoxSlotPositionIGSNComments
1 0,52 0,52 485,3 485,82 NN no 485,3 30 2 M BGRB5011RSRK001
2 0,52 0,52 485,82 486,34 NN no 485,82 30 3 M BGRB5011RSSK001
3 0,54 0,54 486,34 486,88 NN no 486,34 30 4 M BGRB5011RSTK001
4 0,5 0,5 486,88 487,38 NN no 486,88 30 5 B BGRB5011RSUK001
5 0,44 0,44 487,38 487,82 NN no 487,38 31 1 T BGRB5011RSVK001
6 0,08 0,08 487,82 487,9 NN yes 487,82 31 1 M BGRB5011RSWK001

Measurements, descriptions and images:

SectionMSCL-Meas.Spectro-Meas.XRF-LightXRF-MediumXRF-HeavySection Desc.VCD-FileThin Sections360° ScanSlabbed Scan
1 X X X
2 X X X
3 X X X
4 X X X
5 X X X
6 X X X

Samples:

SectionHalfTypeTop (cm)Bottom (cm)Top Depth (m)Top MCD (m)Volume (cc)RequestIGSNSampleComments
1 W --- 9 12 485,39 485,39 65 MSP0002 BGRB5011RX1D001 1264 melt lens with lighter halo
1 W --- 17 25 485,47 485,47 65 MSP0001 BGRB5011RXO7001 1071 thin section /chemical analysis, destructive, remains in storage (BGR)
2 W --- 31 34 486,13 486,13 65 MSP0004 BGRB5011RX73001 910 half core for physical properties, sample will be drilled, but not destroyed
4 W --- 25 27 487,13 487,13 65 MSP0002 BGRB5011RX2D001 1265 white vein parallel to fluidal texture, with sm
5 W --- 8 10 487,46 487,46 65 MSP0002 BGRB5011RX3D001 1266 thin (2-3 mm) porous alteration vein disloca
